D9 8inch 15-36W
Product information
Input Voltage: AC100-240V 50/60Hz
Operation Voltage: DC36-42V
Power Factor: 0.75-0.9
IP Rating: IP20
Life Span: 50,000 hours
Product details
• SMD2835 as light source
• CB Approved driver
• In-house design
• Easy Recessed installation
• ENEC,CE,RoHS,CB
• 3 Years warranty
Construction Features
• Die-case housing as heatsink
• High transmission PC cover
• Various of installation clip
Technical Features
• Input Voltage: AC100-240V 50/60Hz
• Operation Voltage: DC36-42V
• Power Factor: 0.75-0.9
• IP Rating: IP20
• Life Span: 50,000 hours
• Operation Temperature: -15°C~+50°C
• Storage Temperature: -25°C~+55°C
Datasheet
|
Product Name |
Product Code |
Rated Power |
Product Size |
Cut-hole |
Input |
LED |
Power Factor |
Luminous Flux (LM) |
Lumen Efficacy(LM/W) |
CRI |
|
8”/25W |
ED-R8A25-D9 |
25W |
228*77mm |
D192 |
AC100-240V |
SMD2835 |
PF>0.9 |
1850-2100lm |
85 |
Ra>80 |
|
8”/30W |
ED-R8A30-D9 |
30W |
228*77mm |
D192 |
AC100-240V |
SMD2835 |
PF>0.9 |
2250-2400lm |
85 |
Ra>80 |
|
8”/36W |
ED-R8A36-D9 |
36W |
228*77mm |
D192 |
AC100-240V |
SMD2835 |
PF>0.9 |
2600-2900lm |
85 |
Ra>80 |
