Key Features
• SMD LED 2835 (Epistar or Samsung)
• Lumen/CRI: 130lm/w @CRI80/90
• Housing material: die-casting aluminum
• Driver: Isolated Driver  PF>0.95 PF>80%
• CE,RoHS,SAA
• IP44
• 3-5 Years warranty

Technical Features
• Input Voltage:  AC100-240V 50/60Hz
• Operation Voltage: DC36-42V
• Life Span: 50,000 hours
• Operation Temperature: -15°C~+50°C
• Storage Temperature: -25°C~+55°C

Construction Features
•With stronger heat-sink and higher lumen output. Very comfortable and uniform light;
•High lumen output powered by high performance Samsung or Epistar with consistent color temperature;
•Replace CFL Downlight and metal halide Down Light perfectly, UGR<19;
•IP44 protection grade guarantee system to be in moisture environment and inspect proof.
•Complete kit with Triac dimmable or 0-10V dimmable driver or Zigbee system.

Datasheet

Product name	Product Code	Rated Power	Dimension (mm)	Cut-hole (mm)	Input Voltage	LED Type	Beam angle	Power Factor	Lumen/w	CRI
3”/10W	ED-UDA8W-X4	8W	∮106*H34	∮90-95	AC100-240V	Epistar	90	PF>0.95	110-120	Ra>80
3”/15W	ED-UDA12W-X4	12W	∮140*H36	∮125-135	AC100-240V	Epistar	90	PF>0.95	110-120	Ra>80
