Advantages:

1. 15°-55° Stepless zoomable

2. Color adjustable 3000K/4000K/5700K

3. Dim to Warm: 1800-3000K, 2000-3000k

4. Tunable white 2700-5000K /3000-6000K

5. Dimmable by button



Key Features

• Size: ∮65x150x139mm

• Lumen/CRI: >100lm/W @CRI80 (whole lamp)
• 6063 brushed aluminum alloy
• In white, black or silver
• Adjustable: Continuous 350° rotation and 90° pivot
• Adapters for choice:1/2/3 phase, compatible with Global,Norlux, etc.
• 3-5 years warranty

 Application

For replacement of CDM tracklights, metal halide and halogen track spotlights

Ideal for indoor commercial lighting, retail lighting, garment lighting, various shop lighting

Ideal for museums, gallery lighting

Ideal for showroom lighting, exhibition lighting  and other partial lighting



Technical Features

Input Voltage:  AC200-240V/ AC90-130V

Power Factor: PF>0.95 Flicker free

Luminous efficiency: >100lm/W @CRI80 (whole lamp)

Adjustable: Continuous 350° rotation and 90° pivot

Life Span: 50,000 hours

Track adapter: 1/2/3 phase universal adapter

Operation Temperature: -15°C~+50°C

Storage Temperature: -25°C~+55°C



Datasheet

Product Code	Rated Power	Dimension (mm)	Beamangle	Input Voltage	LED Type	Power Factor	Lumen LM	CRI
ED-TL-10W-E	10W	∮65x150x139mm	10-55°	AC100-240V	COB LED	PF>0.95	800-1000	Ra>80
ED-TL-15W-E	15W	∮65x150x139mm	10-55°	AC100-240V	COB LED	PF>0.95	1200-1500	Ra>80

15DEGREE



55Degree
