Advantages:
♦ High CRI: 97+ (2700K/3000K/4000K)
♦ Good quality driver, flicker-free, PF>0.95
♦ 1 /2 / 3 phase universal track adapter
♦ High luminous efficiency>100lm/W @CRI80
♦ Wattage: 10W 15W, 25W, 30W
Inquiry Now

Key Features
•Size: Φ95xL165mm
•  Citizen COB LED with CRI>97
• Lumen/CRI: >100lm/W @CRI80 (whole lamp)
•6063 brushed aluminum alloy
• In white, black or silver
• Adjustable: Continuous 350° rotation and 90° pivot
• Adapters for choice:1/2/3 phase, compatible with Global,Norlux, etc.
• 3-5 years warranty

Application
For replacement of CDM tracklights, metal halide and halogen track spotlights
Ideal for indoor commercial lighting, retail lighting, garment lighting, various shop lighting
Ideal for museums, gallery lighting
Ideal for showroom lighting, exhibition lighting  and other partial lighting

Technical Features
• Input Voltage:  AC200-240V/ AC90-130V
• Power Factor: PF>0.95 Flicker free
• Luminous efficiency: >100lm/W @CRI80 (whole lamp)
• Adjustable: Continuous 350° rotation and 90° pivot
• Beamangle: 10°, 20°, 30°
• Life Span: 50,000 hours
• Track adapter: 1/2/3 phase universal adapter
• Operation Temperature: -15°C~+50°C
• Storage Temperature: -25°C~+55°C

Datasheet

Product Code	Rated Power	Dimension (mm)	Beamangle	Input Voltage	LED Type	Power Factor	Lumen LM	CRI
ED-TL-25W-F	25W	95*165*165	10°/20°/30°	AC100-240V	Version4 Citizen 1205 COB LED	PF>0.95	1800-2100	Ra>97
ED-TL-30W-F	30W	95*165*165	10°/20°/30°	AC100-240V	Version4 Citizen 1206 COB LED	PF>0.95	2200-2500	Ra>97
ED-TL-35W-F	35W	95*165*165	10°/20°/30°	AC100-240V	Version4 Citizen 1206 COB LED	PF>0.95	2700-3000	Ra>97
